How Green Are Our Valleys: Green tuff from Yadoriki Stream of Tonodake Subgroup やどりき水源林




Er, to begin with the pebbles I show from this week are collected with permission for a Kanagawa Forest Instructor (i.e., me) and for study trips with experts for Kanagawa Earth Science Association. As the places I found these are in the Quasi-national Park of Tanzawa-Oyama 丹沢大山国定公園, we cannot collect such things privately. If you plan to geo-hunting nearby, please find frontier places between Quasi-national Park and non-Park zone, such as under Oterabashi Bridge of Yadoriki Community 寄大寺橋付近. Otherwise, please just observe the pebbles and rocks in situ and return them where you find it after you pick them up. Please be careful. Anyway, first let’s return to the now familiar map.


I pasted pebbles I found in Yadoriki Stream 寄沢 in this map which received two arrows almost at the center of illustration. Yadoriki Water Source Forest やどりき水源林 is around there in the center, on the foothills of Mt. Nabewari 鍋割山 (ASL 1272m) and Ameyama Pass (ASL 953m) 雨山峠. Could you see it is on the border between the pale green Togatake Subgroup 塔ヶ岳亜層群 and dotted strip which shows the area where hornfels dominate the ground? Also, Ameyama Pass is at the beginning of the red area (to which I will return next week). It means, as Tokawa Park 戸川公園, Yadoriki Water Source Forest can be a place where pebbles from pale green, red and dotted areas can tumble down. Sure enough, the first exhibits are

1

2

3

4

They are green tuff. They were originally volcanic ashes of undersea volcanoes on Philippines Plate. The piled-up ashes showered by geothermal water with silicon dioxide, metamorphosed and obtained greenish colors. Typical for Tanzawa’s green tuff, they have whitish parts that are quartz. The characteristics of Tanzawa’s quartz is, often they are not large crystal but mixed with grains from chlorite group. It makes the pebbles very hard and relatively smooth, but does not allow light to pass through. Also standard for Tanzawa’s stones, they all do not stick to magnet as the area is famous for no-(substantial)-existence of iron. The microscopic views for each tell us interesting beauty of planet earth. The first is from Tuff 1.


The mixture of slight green with white and nets of brown lines tells us geothermal shower it had contained variety of minerals, including iron. All the elements solidified by cooling and iron was oxidized. The next is Tuff 2.



Could you see tiny tiny crystals are developing here, which look like wet granules of sugar. This is also typical from Tanzawa’s green tuff. The variety of colors we find tells there were many kinds of minerals in original volcanic ash and geothermal water. The were coagulated under high tectonic pressure and had such expression. And for Tuff 3,




It shows yellowish grain of pyrite within sugar-like texture. The second photo is the scenery when I lighted it with UV 365nm. The edge of white and small grains fluoresces in fresh green yellow. When silicon dioxide crystalizes, it absorbs petite amount of uranyl ion that tends to gather on the edge of crystal. (Radioactive!!) When we light the part with UV light, it emits the characteristic light like this. Such feature is again typical for Tanzawa’s rocks. Don’t you think it beautiful? The last photo is for Tuff 4.



We can find sugar-like grains of different colors. They are packed tightly in the first photo. The second is with UV light. The way it emits the fluorescent colors varies from cream-colored to purplish blue. It means the ashes received geothermal shower for quite a long time, and the contents of the shower varied from chalcedony-heavy, zeolite-main, calcite-highest…


Even without going riverbank,
ground of Yadoriki Forest is full of pebbles.

The area Yadoriki Water source Forest is named “Yadoriki Layer” 寄層 of Tonodake Subgroup, with 3km or so thickness. It is 17 million years old main layer of volcanic tuff metamorphosed by geothermal reaction by undersea volcanos of Philippines Plate. Banks of Yadoriki Stream have many exposures of the layer, and so the pebbles we can find there are coming very near from the original place. They can keep angular forms and uneven veins without much abrasion. And they are not only green tuff, but andesites and basalts. Next week, I show you some I found in Yadoriki.



If you find environmental issues in Kanagawa Prefecture, please make a contact with

Kanagawa Natural Environment Conservation Center 神奈川県自然環境保全センター
657 Nanasawa, Atsugi City, 243-0121
〒243-0121 厚木市七沢657
Phone: 046-248-0323

You can send an enquiry to them by clicking the bottom line of their homepage at http://www.pref.kanagawa.jp/div/1644/

Sunday, November 15, 2026

Metamorphose: Togatake Subgroup stones found in Tokawa Park 塔ヶ岳亜層群




Geologically, the west of Oyama Subgroup is Togatake Subgroup which spreads deep down of the main ridge of Tanzawa mountains. From north, Mt. Sodehira 袖平山 (ASL 1432m), Mt. Hiru 蛭ヶ岳 (ASL 1673m), Mt. Tanzawa 丹沢山 (ASL 1567m), and Mt. Nabewari 鍋割山 (ASL 1272m) stand on the layer. Basically, the subgroup was for pyroclastic rock spewed out from the undersea volcanos on Philippines Plate 17 million years ago. Not only taller but also qualitatively, the rocks for the old Togatake Subgroup is different from younger Oyama and Susugaya Subgroups. The young ones are mainly tuffs that were piled up volcanic ashes over the seabeds. The old Togatake Subgroup was very near to the undersea volcanic craters. The ejacta included larger mass such as violently spewed lapilli and magma. Sometimes they were mixed all together with volcanic ashes and become tuff breccia. Here is a gabbro I found in Tokawa Park.


It’s plutonic rock from slowly cooled magma in deep underground. Here we can recognize large crystals typical for slowly cooled magma. The characteristics for Togatake Subgroup is not only this. About 4 to 5 million years ago magma intruded from beneath and the mass received uber high heat and pressure. There are several theories why this happened. One sure thing is it was due to the crash of Honshu Island Arc on Eurasian Plate and Izu-Ogasawara Island Arc on Philippines Plate. Such collision of island arcs can induce magma quickly rising and cooling from the beneath. It’s like a huge dome-shaped volcanic mountain was formulated beneath the crustal-shortened layers on Philippines Plate. “Foothills” of this volcano spreads to 10km beneath Mt. Oyama (ASL 1252m) and Miyagase Dam on Oyama Subgroup. In contrast, the main ridge of Tanzawa was nearer to the “peak” of the underground “volcano” and pushed not only from the collision of plates but also from beneath for the longest period of time. The mountains get taller and taller for 17 million or so years with heat and pressure from below. It metamorphosed the ash-lapilli-magma mixture. Here is the altered one I found in Tokawa Park.


It is hornfels metamorphosed from tuff. When the mass was cracked by humongous pressure of the planet, a very hot quarts-solution seeped in, cooled and crystalized to make a white band. Next one, with its microscopic photo, from Tokawa Park is another transformed green tuff.



It’s epidote. Long prismatic crystal is clear in microscopic view. Don’t you think it’s shockingly beautiful … The next one is also typical from the area.



It’s a metamorphosed basalt. The microscopic view show still angled white grains = crystals of plagioclase which can be formed from slowly cooling magma deep underground. The overall greenish impression is due to the influence of heat and pressure on rapidly cooled magma = basalt. It surely is different from the rocks made of slowly piling up volcanic ashes. And today’s final is this hornblende hornfels.



At the beginning, it was cooling magma from which lots of gas went out from the holes covering the entire surface of a rock. It then received extremely high heat and pressure which turned the color of basalt into greenish. As this has a white streak with yellowish grains, the heat was brought from hot water containing quarts, plagioclase and pyrite. Metamorphose was happening on the basalt from the underground volcano. Well, this “volcano” becomes over the surface in Yadoriki. Next week, let’s return Yadoriki Water Source Forest.


At the entrance of Tokawa Park, there is Tanzawa Visitor Centre. The contact address is

Hadano Visitor Center for Tanzawa-Oyama Quasi-national Park
丹沢大山国定公園・自然公園秦野ビジターセンター

1513 Horiyamashita, Hadano, Kanagawa Prefecture, 259-1304
〒259-1304 秦野市堀山下1513

Phone: 0463-87-9300
https://www.kanagawa-park.or.jp/tanzawavc/

Sunday, November 8, 2026

Useful Rocks: Picking up Stones in Tanzawa V



Outcrop in Tonodake Subgroup.
Greenish strata are typical for Tanzawa Group.

As Tanzawa area is near to Tokyo, the place has been utilized in many ways for human activities for centuries. One of such service the mountains provided was, surprise, surprise (at least for me), mining. The place once had several veins commercially operated till about 60 years ago. They were very thin lodes. In addition, the quality of minerals harvested from there was not high. They died down eventually and disappeared. Still, for example in Tokawa Park, the remnants of such activities can be found in pebbles. Before starting, let’s remind Tanzawa’s geological map we referred to these several weeks.


We’re still remaining Mizunashi River of Tokawa Park at the point of black arrow. The Park is in Hadano Basin 秦野盆地 next to “blue” Oyama Subgroup 大山亜層群. Right next to this Oyama Subgroup, there is Tonodake Subgroup 塔ノ岳亜層群, colored pale green in the map. The pebbles of past mining activities come down to Tokawa Park from Tonodake Subgroup. Here is the first stone for today found in Tokawa Park.


It’s a natural whetstone from around the end of Tokawa Forest Road that is the most upstream area of Mizunashi River 水無川 in Tonodake Subgroup. It is considered that the stone has been well-known since B.C. People excavated the stones from several ruins of that time in south Hadano Basin, together with early iron tools for rice cultivation. The public record of the early 19th century, 新編相模国風土記稿, mentioned the stone “Tokawa Whetstone” as popular product among local commoners who needed whetstone for daily-use farm and kitchen tools. As a whetstone, straight volcanic rocks from cooled magma deep underground are too hard. Instead, when magma with lots of silicon dioxide cooled rapidly near or on the surface ground, it becomes rhyolite with very small uniform particles of quarts and feldspar. When such rhyolite receives hot spring bath from volcanos, feldspar turned soft sericite and kaolin. The hard particles of quarts and feldspar are mixed with soft sericite and kaolin, and Voilà, whetstone is born. We can somehow observe this orchestra of stone particles from this microscopic photo of the above whetstone.


We can see powdery particles of quarts and sericite/kaolin dotted with yellowish pyrite and greenish epidote. The smoky green that come from pyrite and epidote is a trademark for Tokawa Whetstone. According to the way whetstones made naturally, it’s obvious the right heat was needed from magma at several stages of formation. Thanks to the Plate Tectonics, Tonodake Subgroup received it millions of years ago. And our sharp-eyed ancestors found it useful thousands of years ago. Hm. The next one is also useful for keen-eyed humans. It’s a rough piedmontite, found in Tokawa Park.


The headwaters for Mizunashi River are in south folds of Mt. Toh 塔ノ岳 (ASL 1491m). There especially the area of ASL 1,065m to 1,341m around Mt. Shindainichi 新大日 (ASL 1340m) there are thin lodes of manganese. When Japan started total war in the early 1930s, development of manganese mine was very fashionable everywhere. (Manganese can fortify iron and thus improve the quality of guns of that period.) The mine here in Tanzawa was one of such mines. A prospecting here begun in 1933. Then almost all the cities in Japan turned into piles of rubbles thanks to American carpet bombings, and Japan lost the war in 1945. Tanzawa’s mining for manganese of inferior quality died down around 1949. But surely, there remain lodes and the rocks and pebbles come down the water of Mizunashi River. The stone I found in Tokawa Park is one of them. Its microscopic views show us many slightly different surfaces from point to point.

Pinkish

Black millefeuille-like feel is there.

Tanzawa’s rocks containing manganese were originally at the bottom of ocean on Philippines Plate. They were ashes, aka chert, from underwater volcanoes piled up at the bottom. It contained quarts and manganese. Crustal shortening due to the crush of Philippines and Eurasian Plates pushed up the deep-sea sediments. Next there occurred intrusion of plutonic magma (more to it next week) deep down the shortened crust. The magma emitted high heat and pressure to the chert and metamorphosed it into piedmontite, which is a mixture of manganese, quarts, and other minerals. The stone here is a part of this story. Have you noticed something in common for the first whetstone and the piedmontite? Both were metamorphosed tuff by uber strong magma. This is the difference between Oyama Subgroup and Tonodake Subgroup. I’ll talk about it next week. Stay tuned. 😉 Oh, I should not forget about it. These mining sites on the slope of Mt. Toh are located at the points very difficult for casual hikers to approach. The roads once there were abandoned more than 50 years ago. In 2026, you need professional guides to find the way. Moreover, as I’ll tell you eventually the reason, the soil there is easy to collapse, i.e. VERY VERY dangerous to go. Please do not risk your life!

Hmmm. Looks pinkish ...
 in Tonodake Subgroup area.

At the entrance of Tokawa Park, there is Tanzawa Visitor Centre. The contact address is

Hadano Visitor Center for Tanzawa-Oyama Quasi-national Park
丹沢大山国定公園・自然公園秦野ビジターセンター

1513 Horiyamashita, Hadano, Kanagawa Prefecture, 259-1304
〒259-1304 秦野市堀山下1513

Phone: 0463-87-9300
https://www.kanagawa-park.or.jp/tanzawavc/



Sunday, November 1, 2026

My Catch from Oyama and Susugaya Subgroups: Picking up Stones in Tanzawa IV




Could you return the below map? It’s explaining geological subgroups in Tanzawa Area 丹沢. We did the first stone hunting in Togawa Park 戸川公園 at ☆. The Park is in Hadano Basin 秦野盆地 next to “blue” Oyama Subgroup 大山亜層群. Right next to this Oyama Subgroup, there is Tonodake Subgroup 塔ノ岳亜層群, colored pale green in the map. Also east of Oyama Subgroup, there is Susugaya Subgroup 煤ヶ谷亜層群 colored smoky green. Interestingly in Togawa Park, we can pick up stones tumbled down and carried by Mizunashi River 水無川 from these two subgroups as well.


Susugaya Subgroup is the youngest strata made of volcanic ejecta spewed out from underwater volcanoes on Philippine Plate some 13 million to 8.5 million years ago. This was the period when the violent magmatic activities were ending. The soil below Nanasawa Forest Park 七沢森林公園 (; my post for November 8, 2019), around Miyagase Dam 宮ヶ瀬ダム (; my post for April 29, 2019), and the entire itinerary for Iiyama Kan’non Hiking Course 飯山観音 (; my post for November 30, 2018) belongs to Susugaya Subgroup. It has gigatons pyroclastic rocks, straight tuff and mudstone which shows more than 1800m thickness where the mass is the largest. With a simple glimpse, I just wonder how these stones reach from there to Hadano, crossing Mt. Oyama, ASL 1252m 大山. But the stones are there. The first catch of mine is,


Basically, it is smoky pale green pebble with whitish hue. It can easily have a scratch, i.e. soft. It’s celadon. The characteristics of central Tanzawa’s underground is intrusion of huge mass of magma (more to it later) that affected above strata with superhigh heat and pressure. The central Tanzawa (like Yadoriki area) and western Tanzawa is made of such affected strata that have transformed tuff and mudstone into schist due to the impact. In contrast, the force has not reached directly Oyama and, especially, Susugaya Subgroups. Consequently, the basic ground of the areas is comparatively softer and keeps whitish or smoky color in general which is the original texture of tuff and mudstone of underwater volcanic activities. Celadon is the product of less-violent tectonic movement. A microscopic photo of it is this.


We can find smoky green/blue granules. It probably was created during the formation of tuff. They are made of clay with iron and magnesium. These minerals were trapped between the cracks of tuff and received hydrothermal alteration during the tectonic activities. However, the impact of geological heat and pressure was from the ending volcanic process. It could not alter the rock into uber hard mass. I felt this pebble has soft impression. I recalled the places of Susugaya Subgroup I’ve visited. They had definitely more relaxed atmosphere compared with deeper Tanzawa.


In Togawa Park, I also found a relative of the above pebble. It’s dacitic tuff. Unlike the celadon above, it is hard. The microscopic photo tells us the stone is solidified hard granules of white ones (quarts and/or feldspar) and greenish ones.





In the high heat and pressure environment these green-tinted volcanic granules absorbed olive-colored elements from celadon, epidote and chlorite, and rapidly cooled. It’s typical for dacite formation. Containing the element of soft celadon, dacite keeps the characteristics of hard magma. The days and the place Tanzawa’s dacite and celadon were formed could be close, in planetary calendar of course, but they became different stones. Very romantic … Actually Tanzawa area has different kinds of minerals in such a small area. The place once had several veins commercially operated till about 60 years ago. They were very thin lodes. In addition, the quality of minerals harvested from there was not high. They died down eventually and disappeared during the 1960s. But still in Togawa Park, we can collect remnants of them. I’ll show off my catch washed down from such places next week. 😉




At the entrance of Tokawa Park, there is Tanzawa Visitor Centre. The contact address is

Hadano Visitor Center for Tanzawa-Oyama Quasi-national Park
丹沢大山国定公園・自然公園秦野ビジターセンター

1513 Horiyamashita, Hadano, Kanagawa Prefecture, 259-1304
〒259-1304 秦野市堀山下1513

Phone: 0463-87-9300
https://www.kanagawa-park.or.jp/tanzawavc/

Sunday, October 25, 2026

My Catch in Togawa Park I, from Oyama Subgroup: Picking up Stones in Tanzawa III




A hem. So, this week I show off my catch from Mizunashi River 水無川 in Tokawa Park 戸川公園 this summer. First, let me repeat the map I showed you last week.


Let’s begin with the stones from Oyama Subgroup 大山亜層群, colored blue on the above map. Yeah, Tokawa Park is in Hadano Basin, but these stones have tumbled down from deeper inside Tanzawa 丹沢. I tell you why we thought so one by one. Oyama Subgroup is nearest to the Park. The first is this.


Don’t you think it has greenish hue? I think it’s green tuff. They were originally volcanic ash and magma spewed out from undersea volcanos that were very active some 17million years ago on Philippines Plate. Very hot sea water with high pressure at the bottom of the ancient ocean created chlorite from the silica-containing magma that gave the rock green pigment. A microscopic view for its surface is this.


Many kinds of granules there. The stone does not change color when we wet it. It means these small pieces stick together so tightly that water does not steep in easily. It’s an evidence how hot and with heavy pressure were applied when they became tuff. We can find the layer of green tuff in Oyama Subgroup area next to Togawa Park. The average thickness of Oyama Subgroup is about 4000m. Lots of green tuff made of ash is there and a mass of cooled magma also became a part of 4000m. Oyama Subgroup has exa-tons of basalt, like





In large rocks in Tanzawa, basalts were often trapped in hardened volcanic ash which became tuff. When a rock of tuff was crumbling into piece, the confined remnants of volcanic magma like these were released. The white dot in the first stone here may be zeolite and/or calcite from ground water that filled holes after volcanic gas was released when magma was cooling. Also, as Oyama Subgroup was made from underwater volcanic activities millions of years ago, the area has fossils of oceanic creatures buried under the pile of volcanic ash. Here is an example:


Fossils? This one? Oh yes. This piece has lots of fossils of forams. Could you recognize a sort of flattened tiny rugby balls inside? Here’s its microscopic photo.



The stone containing these fossils was cut from “above” to show their rugby ball form. I polised it by sandpapers. The most famous form of forams is star shaped, but many forams have pancake shapes. Here we’re observing fossils of pancake-like Nephrolepidina lived some 15 million years ago 240km offshore from Tokawa Park. When we cut them half in the middle and see them from side, they look like a flattened rugby ball. Forams are tiny protists which have calcareous test (“shell”). Especially for those floating in the ocean, the speed of evolution is very fast and they diversify themselves in numerous forms. Such speedy change gives us a good indicator of time for the formation of a rock when they were entrapped. These squashed rugby balls lived in the ancient Pacific Ocean some 15 million years ago, i.e. the formation of this rock was around that time. They were carried in the rock from offshore, crushed with Eurasian Plate, and raised from the bottom of the sea to the ASL 290m (at Okura Bus Terminal 大倉バス停) and up for Oyama Subgroup. Oh, one thing. Now in Tokawa Park, we cannot find fossils. The above stone was collected from another point of Oyama Subgroup. There are several locations in the Subgroup where we’re still able to find fossils easily. I don’t tell you where in this blog. Sorry. 😉


I also found this in Togawa Park. A mixture of hard epidote and tonalite.


With microscopic view, we can enjoy granules of greenish epidote and black-white tonalite whose part is oxidized and turned brownish.



Beautiful, isn’t it? GoogleGemini said this stone could be a metamorphic tonalite. Deeper down Tanzawa Group, there is a huge mass of tonalite made of magma (more to it next week). It came there by intruding into the crustal-shortened underwater volcanic ashes et al on Philippines Plate. The tonalite received terrific heat and pressure from the tectonic clash. Especially under Oyama Subgroup, the piling up magma and ash contain lots of iron and calcium that are dissolved in the underground water. These elements met with tonalite, chemically reacted and produced epidote. This one also could have the same history. But it’s more closer to tonalite.


Tokawa Park is certainly on the border between Hadano Basin and Oyama Subgroup. But Mizunashi River and its system can carry another types of stones from neighboring subgroups. I show you next week my catch travelled from these areas to Hadano Basin. Please stay tuned!
